NEW AGT KX12-CB 13.5HP Mini Excavator B&S Engine Pilot Control Hydraulic Thumb

by
NEW AGT KX12-CB 13.5HP Mini Excavator B&S Engine Pilot Control Hydraulic Thumb
item image
 BUY NOW ON EBAY
Facebook Twitter Pinterest

Price: 6,988.00 USD

NEW AGT KX12-CB 13.5HP Mini Excavator B&S Engine Pilot Control Hydraulic Thumb

Key Features

  • Ultra-Compact Design: Only 39 inches wide (990 mm) and weighs 900kg, allowing access through standard doorways and perfect for residential and indoor projects.
  • Oil Drain Pipes: Oil drain pipes for travel motor and swing motor.
  • Zero Tail Swing: Allows the excavator to work in tight spaces without the risk of hitting obstacles behinds it. This makes it ideal for jobs with limited space.
  • Boom Swing Design: Allows the operator to move the arm of the excavator horizontally, left or right, without having to reposition the entire machine.
  • Hydraulic Control: Uses hydraulic pressure to operate functions of the machine, such as boom, arm, and bucket.
  • Pilot Control System: Smooth, responsive joystick controls reduce operator fatigue and provide precise machine operation.
  • Powerful Gasoline Engine: 13.5HP Briggs & Stratton engine delivers reliable power with easy maintenance and quick starts in all conditions.
  • Rubber Track Undercarriage: 180*72*37 rubber tracks provide excellent traction and minimal ground disturbance while protecting sensitive surfaces.

Technical Specifications

Basic Performance Parameters

Parameter Value
Operating Weight 900 kg (1,984 lbs)
Bucket Capacity 0.03 m³
Travel Speed Low/High 0-1.8 Km/h
Gradeability 11%
Max Digging Height (A) 2900 mm (114.17 in)
Max Dumping Height (B) 2100 mm (82.68 in)
Max Digging Radius (E) 3250 mm (127.95 in)
Min Swing Radius (F) 1470 mm (57.87 in)
Min Tail Swing Radius (G) 800 mm (31.5 in)
Blade Max Lift Height (H) 190 mm (7.5 in)
Blade Max Dig Depth (I) 190 mm (7.5 in)

Chassis Dimensions

Parameter Value
Overall Length (J) 3240 mm (127.5 in)
Overall Width (K) 990 mm (39 in)
Overall Height (L) 2200 mm (86.5 in)
Wheelbase (M) 930 mm
Track Gauge (N) 810 mm
Blade Width/Height 950 mm / 235 mm (37 in / 9.25 in)

Engine System

Parameter Value
Engine Brand Briggs & Stratton
Engine Model 13.5HP
Max Power 9.8 kW
Max RPM 3600
Cylinders 1
Cooling System Air-cooled
Engine Oil Capacity 1.1 L
Fuel Type Gasoline
Fuel Grade 95#
Theoretical Fuel Consumption 0.5-1.2 L/h

Hydraulic System

Parameter Value
Main Pump Type/Model Gear Pump / 06
Main Pump Brand Tianjin Walking
Rated Pressure 16 Mpa (2320 PSI)
Main Pump Max Flow 21.6 L/min (5.7 GPM)
Control Valve 8-Spool Valve
Control Valve Brand Taiheng
Valve Rated Pressure 16 Mpa (2320 PSI)
Travel Motor Type BM6-315
Travel Motor Brand Cohen / Liyuan
Travel Motor Displacement 315
Swing Motor Type BM2-315
Swing Motor Displacement 315

Undercarriage

Parameter Value
Rubber Track (Width*Pitch*Links) 180*72*37

Item specifics

Condition
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is …
Model Year
2025
Compared to KX12-CBD
No Expandable/Retractable Tracks
Make
AGT
Equipment Type
Mini Excavator
Country of Origin
China
Operating Weight
Under 3,000 lbs
Purchase Note
PLS make sure that you have a forklift for unloading before buy
UPC
Does Not Apply
